Optical glass
Key words:
Optical glass
Category:
Product Details
The center is thicker than the edge and has a converging effect on the light, so it is also called a converging lens. According to different shapes, convex lenses can be divided into biconvex lenses, plano-convex lenses and meniscus lenses, etc., by refracting light to change its propagation direction, so as to achieve the effect of image magnification, reduction, handstand or upright. The special shape leads to its unique optical properties. When the light passes through the cylindrical mirror, the light will be focused into a straight line or other forms of deformation. This property gives cylindrical lenses significant advantages in changing the size of the image, such as converting a point spot into a line spot, or changing the height of the image without changing the image width.
- Product Description
-
- Common Materials
Material
Refractive Index (nd)
Dispersion Coefficient (Vd)
Density (g/cm3)
Transmission Range (um)
Thermal Expansion Coefficient (10-6/K)
BK7
1.517
64.2
2.52
0.33-2.1
7.5
SF5
1.673
32.17
4.08
0.33-2.5
8.2
SF11
1.785
25.76
4.87
0.37-2.5
6.8
Fused Silica
1.458
67.82
2.2
0.185-2.5
0.54
Prexy
1.474
65.38
2.23
0.23-2.7
3.25
CaF2
1.434
94.99
3.18
0.17-7.8
18.85
Sapphire
1.768
72.24
3.99
0.18-4.5
5.8
Features
Economical
High Precision
Surface
Flat
Flat
Dimensional Tolerance
+/-0.1mm
+/-0.01mm
Surface Quality
40-20
10-5
Surface Flatness
λ/4
λ/10
Parallelism
20″
2″
Perpendicularity
15′
5′
